Samsung SM431 Pick and place machine

Placement Speed : 55,000CPH
Applicable PCB : Max. L460ⅹW460ⅹ1lane
Applicable Part : 0402 ~ □ 12mm (H = 7mm)
Accuracy: ± 50㎛ @ μ + 3σ / chip

BASIC INFO

Samsung SM431 Pick and place machine

Samsung SM431 efficient and wide range of support for all forms of production,

with its class in the world's fastest, universal type surface mount machine can mount a wide
range of components, the specific realization of "Limitless EXpansion" a number of
functions as Standard configuration, to ensure high-quality placement of a highly flexible feeding device.

Samsung SM431 parameters
1) Speed 55,000CPH (Best condition)
2) dual-arm Y-axis dual servo drive system
3) arms a total of 16 placement head
High-speed flight image recognition system
- Components to adapt to: 0402mm Chip to □ 12mm
- Mounting accuracy: ± 50μm @ 3σ
4) For new SM feeding system
- For non-stop feeder
- for the rail way feeder
-LED Displays feeder status
5) dual transmission system
- Dual transfer mode: 330 x 250 (2 PCBs)
- Single transfer mode: 460 x 460 (1PCB)
6) Can put 84 8mm feeders
7) LCD display with front and rear operation
8) automatic mouth change device
9) Windows XP operating system
10) Safety cover

11) Kit
