Yamaha YHP-2 Hybrid pick and place machine
Capable of mixed mounting of SMD components and semi-conductor components
Capable of handling multiple types of the dipping unit
Usable for dipping &stamping by the dipping unit
Applicable for a wide area up to L300mm x W200mm
|
PCB dimensions |
L300xW200mm(Max)～Ｌ３０ｘＷ３０ｍｍ(Ｍin） |
|
|
PCB thickness |
0.1ｍｍ～3.0ｍｍ |
|
|
PCB transport diredion |
Right→left(option；left→right） |
|
|
Conveyor reference |
Front side(option：rear side） |
|
|
Mounting accuracy |
F type |
Absolute accuracy (μ＋３σ):±20μm |
|
|
|
(When using Yamaha's standard components）Repeatability(3σ):±12.5μｍ |
|
|
4Ｍ type |
Absolute accuracy (μ＋３σ):±30μm |
|
|
|
(When using Yamaha's standard components）Repeatability(3σ):±20μｍ |
|
Load control |
F type |
Load control range；１ to 49N |
|
|
|
Load control accuracy；１ to 9.8N:±10% |
|
|
|
Load control accuracy；9.8 to 49N:±5% |
|
|
4Ｍ type |
Load control range；2 to 10N |
|
|
|
Load control accuracy；±20% |
|
Mounting/dispensing cycle time |
4Ｍ type |
0.5sec/CＨＩＰ(When continuos pickup at work) |
|
(Under optimum conditions) |
FF type |
0.8se/CＨＩＰ(Tape reel and tray supply case） 1.3sec/CHIP(Wafer supply case） |
|
*Procee time not included |
FD type |
As the measure as vary depending on the operation, please consult separately. |
|
No. of componebt types |
When using the front side |
36 types(8＋8＋20), 28 types(8＋20)，16 types(8＋8) or 8 types(8×1） |
|
(Max, for 8mm tape conversion) |
8 in-line plate |
*The number of type is reduced depending on equipment of the supply system and supplementary system. |
|
(in front of the conveyor installation position) |
||
|
|
When using the front side |
40 types(20+20) or 20 types (20 x1) |
|
|
20 in-line plate |
*The number of type is reduced depending on equipment of the supply system and supplementary system. |
|
(in front of the conveyor installation position) |
||
|
Component supply configuration |
●Tape reel ●Bulk |
|
|
|
●2,4inch waffle tray (Equipped with an auto-changer） |
|
|
|
●6,８inch wafer (Capable of handling expanded wafer and simple expanding, placing with face-up and face down) |
|
|
Component applicable for mounting |
0402～□15mm component |
|
|
|
(*1:As a special nozzle and a special feeder are required, please consult separately) |
|
|
|
SOP,SOJ,QFP,connector, PLCC,CSP,BGA,PGA,Flipchip,Barechip,Wafer-level CSP, Other special components(Please consult separately.) |
|
|
Power supply |
3-phase AC200/208/220ﾉ240/380/400/416Ｖ±10％ 50/60Ｈｚ |
|
|
Rating |
4.4kVA |
|
|
Average power consumrtion |
0.7kW |
|
|
*When running Yamaha's standard operations |
|
|
|
Air supply source |
0.55Mpa or more, 300l/min.(ANR)(Max), in clean, dry state |
|
|
External dimensions |
L1,350xW1,408xH1,850mm |
|
|
Weight |
Approx. 1,450kg |
|
