TRI TR6836 IC X-ray Inspection Machine

Accuracy: ±(0.5 % of 8V range)
Driver Voltage Range: -2.0V to +8V ( Vih / Vil )
Voltage force: ± 12V
Period resolution: 10ns

BASIC INFO

TRI TR6836 IC X-ray Inspection Machine

TR6836 is the 33 MHz logic IC tester with the best performance-price ratio in the market. It can handle performing functional vector tests as well as DC parametric tests. It has an easy-to-use test program development environment, many debugging and analysis tools, compact size and highly integrated design, making TR6836 a multi-functional engineering verification solution for IC design companies. TR6036 also has 8-site parallel testing capabilities, TTL or GPIB connection interface with test machines and sorting machines, a sound operating interface and powerful statistical functions, making TR6836 the most efficient and influential tool in IC testing factories. Product testing solutions.

characteristic

• 4/8M/16M test vector memory, 4K fail memory
• Complete functional test vector and DC parameter test
• Each channel (PIN) can set the timing generator, level setting, current load and I/O status setting Determined
• 16 groups of on-the-fly timing settings
• 8 groups of independent voltage/current supply and measurement
• 4 groups of power supplies to the IC power pins under test
• Plotting and measuring (point, line) positions Features for engineering analysis
• First-class test program debugging tools and logic waveform display
• Complete test statistics report and bar chart
• TTL or GPIB connection interface with needle tester and classification machine
• 8 sites for parallel testing in mass production
