JT AKP-350 H Wave Soldering Machine
AKP Series of Wave Soldering Machine
● New solution of preheating:
The hot air preheating u- shaped heater has a long service life, and reduces maintenance downtime. Internal reinforcement insulation plus an optional external protection device can effectively reduce the heat loss, energy-saving up to 20% compared with traditional equipment. Lower body temperature with better work enviroment.
● External Spray Fluxer, safety, cost, space, and maintenance problems resolved：
External and independent spray control system, ensure the safety and clean, easy to operate and maintenance; Transportation of new type titanium alloy heavy-duty claw, sectional guide rail design, stainless steel strip supported in guide rail, long life; The solder pot adopts special materials, Anti corrosion coating on surface; Adopt imported precision nozzle, atomization uniformity, high efficient.
● The large promotion of solder pot：
Nozzle quick released, reduce maintenance time, 2 hours to a few minutes; Grid type of mesh, reduce the mesh block by solder dross monthly maintenance extended to six months; Optional auto solder supplying device, reduce the influence of wave height caused by a drop of solder level;
Description
| MODEL No | 350 Series |
| AKP-350 H | |
| Wave Soldering Outside Dimension(L*W*H) | 4445×1582×1735mm |
| External Spray Fluxer Outside Dimension(L*W*H) | 1300×1350×1595mm |
| Power Supply | 3P5W 380V AC 50/60Hz |
| Option: 3P5W 220V AC 50/60Hz | |
| Operating Power | ≤11KW |
| Power For Warm Up | 30KW |
| Air | 0.5Mpa-0.8Mpa Air |
| Control Mode | PC＋PLC |
| Spray Flow | 10~100ml/min |
| Exhaust Pipe Diameter | Φ200mm |
| Air Outlet Mode | Up-down Convection |
| Preheat Mode | Hot Air Preheating / Infrared Preheating |
| Preheat Zones Number | 4 Zones |
| Preheat Temperature | Room Temperature～250℃ |
| Preheating Temperature Control Mode | PID+SSR |
| Working Mode of Tin Furnace | Mechanical Pump |
| Tin Furnace Capacity | Lead-free： About 480KG |
| MAX Temp of Tin Furnace | MAX: 300℃ |
| Wave Driving Power | 1/4 HP×2 |
| Warming Up Time | About 140 min（Setting Temperature：265℃） |
| PCB Transmission Speed | 300~1800mm/min |
| Width Range of PCB | 50-350mm |
| PCB Board Component Height | Top 120mm, Bottom 25mm |
| PCB Inlet Transport Height | 750±20mm |
| Transport Guide Rail Inclination | Factory：5.5°±0.2°（4°— 7°Adjustable ） |
| Cooling Mode | Forced Air Cooling |
| Nitrogen Consumption | 15m³/h below 2000ppm |
| Pressure Nitrogen Source | 0.5～0.8MPa |
| Oxygen Nitrogen Source | ≤10PPM |
| Oxygen Analyzer | option |
