SUNEAST SST-12DA/12DN SMT Double track Nitrongen Reflow Oven
SST SERIES PRODUCT FEATURES:
Durable and interchangeable with double-sided rails with special hardening;
Adopt stainless steel belt chain with guard, anti-clamp, practical and reliable;
New flux recovery system, full modular design, convenient and quick maintenance, reduce maintenance time and cost;
Patented hot air system, more efficient, faster heat compensation;
New furnace structure design, multi-layer heat insulation, effectively reduce the working environment temperature.
| SST series specifications | |||
| Model No | SST-08DA/SST-08DN | SST-10DA/SST-10DN | SST-12DA/SST-12DN |
| Heating System | |||
| Heating Zone | 8 Heating Zones，16 Heating moudules | 10 Heating Zones，20 Heating moudules | 12 Heating Zones，24 Heating moudules |
| Heating Length | 3120mm | 3870mm | 4635mm |
| Cooling Type | Three cooling zones:forced air cooling/water coaling | ||
| Outlet Exhaust Demand,Valume | 2-Φ145， Exhaust demand15m³/minx 2 | ||
| Conveyor System | |||
| Product Width | min50mm-max270mm/ min50mm-max500mm | ||
| Conveying Direction | L→R，R→L | ||
| inlet Height | 900±20mm | ||
| Fixed Rail Side | Front and Rear Rails Fixed，central two rails are movavle | ||
| Conveyor Type | Chain+mesh belt synchronous transmission | ||
| Cmponent Height | Clearance based on the rail：above 30mm， below 25mm | ||
| Conveying Speed | 300mm-2000mm/min | ||
| Control System | |||
| Power Supply | AC3Φ，5W,380V,50/60HZ | ||
| Total Power | 70KW | 89KW | 108KW |
| Start up Power | 35KW | 40KW | 45KW |
| Running Power | 10KW | 11.5KW | 13KW |
| Temperature Range | Room temp to 320℃ | ||
| Control Type | PC+PLC Control System | ||
| Rail Width Adjusting Mode | Electric+Manual | ||
| Temp Control accuracy | ±1℃ | ||
| PCB Temp Deviation | ±2℃ | ||
| Data Storage | Process Data and status stotage | ||
| Power Outage Protection | Equipped with UPS | ||
| Operation Interface | Windows Chinese simplified， English online free switching | ||
| General | |||
| Dimension（L×W×H) | 5580*1735*1620 | 6300*11735*1620 | 7020*1735*1620 |
| Weight | 2700-2900kg | 3000-3200kg | 3300-3500kg |
| Color | Bright wrinkled white | ||
Efficient Technology Co.,Ltd provide a full SMT assembly line solutions, including SMT Production Line, SMT Pick and place machine, SMT Stencil Printer, SMT Inspection equipment, SMT Weling equipment, SMT Intelligent Storage System, SMT Automatic Insertion Machine, SMT Peripheral Equipment, SMT Feeders, SMT Nozzles, SMT Spare Parts etc any kind SMT machines you may need, please contact us for more information: WeChat: +8613714564591 Email: sales@efsmt.com
FAQ:
Q: What we can do for you?
A: One-stop SMT Solution Supplier; Reliable SMT Partner.
Q.What is your MOQ requirement for the machine?
A. 1 set moq requirement for the machine.
Q. This is the first i use this kind of machine, is it easy to operate?
A: Provide free training，There are also English manuals or instructional videos to show you how to use the machine.
Q: If the machine has any problem after we receive it, how can we do?
A: Our engineer will help to solve it first, and free parts send to you in machine warranty period.
Q: Do you provide any warranty for the machine?
A: Yes 1 year warranty will be provided for the machine.
Q: What is your payment terms?
A: 30% deposit in advance and 70% balance before shipment.
