SMT Economical Full Auto PCB Screen Stencil Printer

PCB thickness: 0.6-3mm
PCB weight: ≤3kg
Warranty: 1 year
Lead time : 15 working days

BASIC INFO

SMT Economical Full Auto PCB Screen Stencil Printer

1. Stable steel mesh fixed structure.

2. The track automatically adjusts the PCB width.

3. The lift table is driven by a high-precision screw.

4. Equipped with a reverse splint device, which can improve the bending problem of long boards.

5. The worktable design can be moved and adjusted as a whole, which can ensure that the PCB board is always in the center of the scraper.

6. All-axis linkage reset technology enables the machine to quickly return to the origin position.

7. Fast and simple setting of line change parameters, increase line change speed, slide rail type scraper system, improve operation stability and prolong service life.

8. Programmable suspension printing head: driven by two sets of stepping motors, the pressure of the front and rear blades can be adjusted individually to ensure the front and rear
Printing inconsistency; effectively control the stroke, improve printing efficiency, prevent solder paste from leaking

9. Standard stainless steel scraper, specially designed to improve the service life of the blade.

10. This machine is suitable for manually adjusting the height of PCBs with different thicknesses – to ensure the excellent contact between the PCB and the steel mesh.

parameter

Printing accuracy	≥2 Cpk@±50μm@,6σ
Repeat printing	≥2 Cpk@±30μm@,6σ
Cycle Time	7s
Screen frame	Frame size	470370mm-570750mm
	Screen frame fixed	Cylinder
	Screen frame adjustment	Manual
Steel mesh bracket	Bracket adjustment range	X:±100mm Y:±150mm
Steel mesh bracket	Platform adjustment angle	Z:±2°
PCB	Printing size	Standard: Min5050mm Max380580mm
	PCB thickness	0.6mm-3mm
	PCB weight	≤3kg
	PCB Warpage	The maximum lift is 7mm (including the substrate)
Transmission	Transmission direction	L→R,L→L，R→L，R→R
	Transfer speed	100-1500mm/s programmable adjustment
	Transmission width	50-400mm
Demoulding	Demoulding method	Scraper first and then demould, maintaining pre-pressure for demoulding.
	Demoulding speed	0.1-20mm/s
	Speed distance	0mm-3mm
Working conditions	Voltage requirements	220V, ±10%, single phase 50/60Hz.
	Power requirements	3kw
	Air pressure requirements	0.45-0.6MPa
	Air consumption	0.5ml/s
Safety performance	Insulation resistance	1KV/3MΩ
	Ground resistance	≤0.1Ω
	Operating noise	≤87dB
Machine dimension	1500mm(L)1000mm(W)1650mm(H)
