Anda iCure-4 Inline Infrared Heat Curing Oven
Anda iCure Series are compact, inline infrared (IR) heat curing oven systems. iCure is highly unique, it combines SMEMA height upper and lower (optional) return conveyor curing within the same compact work cell. This enables iCure to perform the job of ovens twice its length for applications that require a second oven to cure coatings, adhesives or inks applied to an inverted Pallet/PCBA. The iCure Series provides manufacturers a 100% reduction in factory oven floor space.
The systems SMEMA communication and touch screen control interface integrates into new or existing factory automation lines or can also be used stand-alone. Pairs seamlessly with selective conformal coating spraying systems.
Standard Features
PLC and touch screen control
Edge carrying, variable speed pin chain conveyor
Rail expansion compensation
SMEMA communication protocol
100 mm top and bottom side component clearances
Thermocouple process control
Independent Infrared (IR) heating zones
Optional Features
Lower return conveyor
Lower return conveyor with IR heat curing zones
iCure-4 Inline Infrared Heat Curing Oven
|
Transmission System |
|
|
Board / Pallet Width |
50-460 mm (1.96″ -18.11″) |
|
Component Height |
± 100 mm (± 3.93″) |
|
Conveyor Height |
900 ± 20 mm (35.43″ ± 0.79″) |
|
Process Flow |
L to R (Standard), R to L (Optional) |
|
Conveyor Speed (XY) |
0.5 – 5 m/min |
|
Convery Width Adjustment |
Manual |
|
Maximum Load |
4 kg/m at even distribution |
|
Temperature Configuration |
|
|
Number of Heat Zones |
4 Heat Zones |
|
Temperature Control Range |
Room temperature – 100 °C (adjustable) |
|
Heating Zone Power |
600W x 7 heat tubes per zone |
|
Temperature Stabilization Time |
10 minutes |
|
Temperature Control Accuracy |
±5 °C |
|
Facility |
|
|
Standard Footprint |
L 4000 x W 1070 x H 1155 mm (L 157.48″x W 42.13″x H 45.47″) |
|
Weight |
1000 kg |
|
Exhaust Requirement |
5 m³/min (177 CFM) |
|
Power |
3 Phase 380 VAC (Standard), 208/480 VAC with transformer (Optional) |
|
Rated Power |
18.0 kW |
|
Interface |
|
|
Controller |
PLC and touch screen |
|
Communication Protocols |
SMEMA & IPC-CFX |
