JUK SMT Electric Stick Feeder SFW1EB SFW2EB SFW3EB SFW4EB SFW5EB
Series#: JUKI Stick Feeder
Product Details
JUKI Electric Stick Feeder SFW1EB SFW2EB SFW3EB SFW4EB SFW5EB
Electronic belt-driven stick feeders provide reliable, high speed component presentation
100% Original and new JUKI SMT feeder for For JUKI SMT machine
Large stock JUKI Feeder,Juki Nozzle for juki industrial sewing machines and for sale
Specification
| Feeder type | SOP | SOJ | PLCC(QFJ) | ||||||||
| Model No. | |||||||||||
| Lane width | nominal size（mil） | W（㎜） | Ｔ（㎜） | nominal size（mil） | W（㎜） | Ｔ（㎜） | nominal size（mil） | W(㎜） | Ｔ(㎜） | ||
| （㎜） | |||||||||||
| Type N0 | SFN0EB | 6.9*1 | 225 | 5.72～6.99 | ～1.5 | – | – | – | – | – | – |
| 6.6～8.9*2 | 2 | ||||||||||
| 300 | 7.62～8.89 | ||||||||||
| Type N1 | SFN1EB | 7.2 | 225 | 5.72～6.99 | ～1.5 | – | – | – | – | – | – |
| Type N2 | SFN2EB | 9.2 | 300 | 7.62～8.89 | 2 | 300 | 8.38～8.76 | 285×325 | 8.05～8.31 | 4.2～5.08 | |
| 3.25～3.76 | |||||||||||
| 290×490 | 8.13～8.51 | ||||||||||
| Type N3 | SFN3EB | 11.2 | 375 | 9.53～10.8 | 2.5 | 350 | 9.65～10.03 | 350×350 | 9.78～10.03 | 4.2～4.57 | |
| 4.2～5.08 | |||||||||||
| 350×550 | |||||||||||
| Type N4 | SFN4EB | 13 | 450 | 11.43～12.7 | 3 | 400 | 10.92～11.3 | 450×450 | 12.32～12.57 | 4.2～4.57 | |
| 12.19～12.57 | 4.2～5.08 | ||||||||||
| 400×550 | |||||||||||
| Type W1 | SFW1EB | 15 | 525 | 13.34～14.61 | 3.5 | – | – | – | – | – | – |
| Type W2 | SFW2EB | 18.2 | 600 | 15.24～16.51 | 4 | – | – | – | 650×650 | 17.4～17.65 | 4.2～5.08 |
| Type W3 | SFW3EB | 20.8 | – | – | – | – | – | – | 750×750 | 19.94～20.19 | |
| Type W4 | SFW4EB | 26 | – | – | – | – | – | – | 950×950 | 25.02～25.27 | |
| Type W5 | SFW5EB | 31.2 | – | – | – | – | – | – | 1150×1150 | 30.1～30.55 | |
