JUKI ISM3600FA Intelligent Storage Management System
A model that enables automatic part transport with ISM 3600
Features
Integration with AMR realizes automation of incoming/outgoing and component conveyor
Adjustable Case Heights: From 8mm to 88mm.
Maximum Storage Capacity: 3,600 reels (using double reel cases).
Batch Storage/Retrieval: Up to 54 reels simultaneously.
Specification
Dimensions (W×D×H[with HCU]）
2,532×1,673×2,453[2,722] mm
Body weight
1,196kg(empty）-1,763kg（with case)
Power consumption
Single phase 200-230V;50/60Hz
Air consumption[with HCU]
0.3kW [1.6kW *]
* HCU2.0 x2 units
Model
Model
Sub model name
Total quantity
7″reel
13″/15″reel
8 mm
16 mm
24 mm
8 mm
16 mm
24 mm
32 mm
44 mm
48 mm
ISM 3600F.A.
7″ONLY
Single case
3,128
2,452
588
88
–
–
–
–
–
–
15″ONLY
591
–
–
–
262
175
88
52
–
14
7″+15″MIX
Single case
1,950
1,312
316
48
119
82
41
25
–
7
